reference waveform to the internal memory or external USB storage device. Then

click or tap Save to complete the save operation. For details about the disk

management operation, refer to the

Disk Management

section in

Store and

Load

TIP

• Only when the reference waveform is saved, can this export function be valid.

• For the ".bin" format file, refer to

Binary Data Format (.bin)

Import from Internal or External Memory

You can import the stored reference waveform file from the internal memory or

external USB storage device to the instrument and display the file on the screen.

Click or tap

Import to enter the reference waveform file loading interface.

• Set the Format

The file format of the reference waveform is specified as "*.ref" which is

displayed in Format.

• Set the Load Path

Click or tap the input field of File Path, then the disk management interface is

displayed.

Through the disk management menu, you can load the current reference

waveform to the waveform view of the oscilloscope. Then click or tap

Load to

complete the load operation. For details about the disk management operation,

refer to the

Disk Management

section in

Store and Load

Reference Waveform

DHO900 User Guide

188
