Click or tap the "Start Frame" input field in

Figure 20.2

to set the start frame for

playing back the waveforms. You can also use the corresponding multipurpose

knob to set the value. The default is 1, and the maximum value is the maximum

number of frames recorded.

5. End Frame

Click or tap the "End Frame" input field in

Figure 20.2

to set the end frame for

playing back the waveforms. You can also use the corresponding multipurpose

knob to set the value. The default is the number of frames of the recorded

waveforms.

6. Current Frame

When the playing is stopped, click or tap the "Current" input field in

Figure 20.2

set the currently displayed frame with the pop-up numeric keypad. You can also

use the corresponding numeric keypad to set the value. The maximum allowed is

the number of recorded frames.

Waveform Recording and Playing

DHO900 User Guide

224
