- If the channel is not displayed, you can press the channel key to open the

channel in the waveform view window.

- If the channel is displayed but not selected, you can press the channel key to

select the channel.

- If the channel is both displayed and selected, you can press the channel key

to close its display in the waveform view.

12. Probe Compensation Signal Output Terminal/Ground Terminal

This terminal outputs the probe compensation signal which helps you match a

probe's input capacitance to the oscilloscope channel to which it is connected.

13. Analog Channel Input Terminals

BNC connectors. Attach probes to these connectors for analog signal inputs.

14. Digital Channel Input Terminal

Attach logic probes to the interface for digital signal inputs.

15. USB HOST Port

This series supports USB storage device of FAT32/NTFS format and mouse.

- USB storage device: imports or exports data (software update, waveform,

setup, or captured image).

- Mouse: connects a mouse to control the instrument.

16. Power Key

Powers on/off the oscilloscope.
