3. Adjust the Cursor Position (note that you can also press
continuously to switch the current cursor)
 Adjust cursor A: press CursorA and use to adjust the position of cursor
A. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
 Adjust cursor B: press CursorB and use to adjust the position of cursor
B. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
 Adjust cursor A and B at the same time: press CursorAB and use to
adjust the position of cursor A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable range is limited within the screen.
4. Select X (Y) Axis Unit
Press Units to set the horizontal unit and the vertical unit of the cursor
measurement.
Press Hori.Unit to select “s”, “Hz”, “Degree” or “Percent”.
 s: when this unit is selected, in the measurement results, AX, BX and BX-AX
are in “s” and 1/|dX| is in “Hz”.
 Hz: when this unit is selected, in the measurement results, AX, BX and
BX-AX are in “Hz” and 1/|dX| is in “s”.
 Degree: when this unit is selected, in the measurement results, AX, BX and
BX-AX are in “°”. At this point, AX, BX and BX-AX will change to “0°”, “360°”
and “360°” respectively when you press Set Range, no matter where
cursor A and B are currently located. At the same time, two cursor lines
(unmovable) appear on the screen as the reference positions.
 Persent: when this unit is selected, in the measurement results, AX, BX and
BX-AX are in “%”. At this point, AX, BX and BX-AX will change to “0%”,
“100%” and “100%” respectively when you press Set Range, no matter
where cursor A and B are currently located. At the same time, two cursor
lines (unmovable) appear on the screen as the reference positions.
Press Vert.Unit to select “Source” or “Percent”.
 Source: when this unit is selected, in the measurement results, the units of
AY, BY and BY-AY will be automatically set to the unit of the current source.
 Persent: when this unit is selected, in the measurement results, AY, BY and
