Rigol DS1000Z Series User Manual

Chapter 3 To Set the Horizontal System RIGOL
DS1000Z User’s Guide
3-7
CH3-CH4” and the two channels corresponding will be enabled automatically
and disabled the other two channels at the same time. X axis traces the voltage
of the later channel of each option and Y axis traces the voltage of the former
channel of each option.
 The following functions are not available in XY mode:
Auto measure, cursor measure, math operation, reference waveform, delayed
sweep, vector display, HORIZONTAL
POSITION, trigger control, memory
depth, acquisition mode, Pass/Fail test and waveform record.
Method 2: Use the shortcut measurement function
Please refer to “Phase A→B ” and “Phase A→B ” measurement functions of “Delay
and Phase” on page
6-21.
