Auto mode
Figure 2-132 Table 2-91 The Mode setting
Menu
Settings
Comments
Mode
Auto
Display the cursors for the current
automatic measuring. (See the following
figure).
Figure 2-133
Auto Measure Mode of Cursor Measurement
There will be no cursor display if no parameters are chosen in Measure menu. The
oscilloscope could move cursor automatically to measure 22 parameters in Measure
menu.
