Chapter 18 Specifications RIGOL
MSO2000A/DS2000A User’s Guide
18-3
Vertical
Bandwidth
(-3 dB) (50 Ω)
MSO/DS2302A/2302A-S: DC to 300 MHz
MSO/DS2202A/2202A-S: DC to 200 MHz
MSO/DS2102A/2102A-S: DC to 100 MHz
MSO/DS2072A/2072A-S: DC to 70 MHz
Single-shot
Bandwidth (50 Ω)
MSO/DS2302A/2302A-S: DC to 300 MHz
MSO/DS2202A/2202A-S: DC to 200 MHz
MSO/DS2102A/2102A-S: DC to 100 MHz
MSO/DS2072A/2072A-S: DC to 70 MHz
Vertical
Resolution
Analog channe: 8 bit
Digital channel: 1 bit
Vertical Scale When the input impedance is 50Ω: 500 μV/div to 1 V/div
When the input impedance is 1MΩ: 500 μV/div to 10 V/div
Offset Range When the input impedance is 50Ω:
500 μV /div to 50 mV/div: ± 2 V
51 mV/div to 200 mV/div: ± 10 V
205 mV/div to 1 V/div: ± 12 V
When the input impedance is 1MΩ:
500 μV /div to 50 mV/div: ± 2 V
51 mV/div to 200 mV/div: ± 10 V
205 mV/div to 2 V/div: ± 50 V
2.05 V/div to 10 V/div: ± 100 V
Bandwidth
Limit
[1]
MSO/DS2302A/2302A-S/2202A/2202A-S: 20 MHz/100 MHz
MSO/DS2102A/2102A-S/2072A/2072A-S: 20 MHz
Low Frequency
Response
(AC Coupling,
-3 dB)
≤5 Hz (on BNC)
Calculated Rise
Time
[1]
MSO/DS2302A/2302A-S: 1.2ns
MSO/DS2202A/2202A-S: 1.8 ns
MSO/DS2102A/2102A-S: 3.5 ns
MSO/DS2072A/2072A-S: 5 ns
DC Gain Accuracy ±2% full scale
DC Offset
Accuracy
±0.1 div ± 2 mV ± 1% offset value
Channel to
Channel Isolation
DC to maximum bandwidth: >40 dB
