RIGOL Chapter 18 Specifications
MSO2000A/DS2000A User’s Guide
Vertical (Digital Channel) (MSO2000A and MSO2000A-S)
Threshold Adjustable threshold of 8 channels per group
Threshold
Selection
TTL (1.4 V)
5.0 V CMOS (+2.5 V)
3.3 V CMOS (+1.65 V)
2.5 V CMOS (+1.25 V)
1.8 V CMOS (+0.9 V)
ECL (-1.3 V)
PECL (+3.7 V)
LVDS (+1.2 V)
0 V
User Def
Threshold Range ±20.0 V, 10 mV step
Threshold
Accuracy
±(100 mV+3% threshold setting)
Dynamic Range ±10 V + Threshold
Minimum Voltage
Swing
500 mVpp
Input Resistance //101 KΩ
Probe Load ≈8 pF
Vertical
Resolution
1 bit
