Trigger
Trigger Level
Range
Internal ± 5 div from center of the screen
EXT ± 4 V
Trigger Mode Auto, Normal, Single
Holdoff Range 100 ns to 10 s
High Frequency
Rejection
[1]
75 kHz
Low Frequency
Rejection
[1]
75 kHz
Trigger
Sensitivity
1 div (below 10 mV or noise rejection is enabled)
0.3 div (above 10 mV and noise rejection is disabled)
Edge Trigger
Edge Type Rising, Falling, Rising/Falling
Pulse Trigger
Pulse Condition Positive Pulse Width (greater than, lower than, within specific
interval)
Negative Pulse Width (greater than, lower than, within specific
interval)
Pulse Width
Range
2 ns to 4 s
Runt Trigger
Pulse Width
Condition
None, >, <, <>
Pulse Polarity Positive, Negative
Pulse Width
Range
2 ns to 4 s
Windows Trigger (Option)
Windows Type Rising, Falling, Rising/Falling
Trigger Position Enter, Exit, Time
Windows Time 16 ns to 4 s
Nth Edge Trigger (Option)
Edge Type Rising, Falling
Idle Time 16 ns to 4 s
Edge Number 1 to 65535
Slope Trigger
Slope Condition Positive Slope (greater than, lower than, within specific
