RIGOL Chapter 18 Specifications
MSO2000A/DS2000A User’s Guide
interval)
Negative Slope (greater than, lower than, within specific
interval)
Time Setting 10 ns to 1 s
Video Trigger (HDTV Option)
Signal Standard NTSC, PAL/SECAM, 480P, 576P (Standard)
720P, 1080P and 1080I (Option)
Pattern Trigger
Pattern Setting H, L, X, Rising, Falling
Delay Trigger (Option)
Edge Type Rising, Falling
Delay Type >, <, <>, ><
Delay Time 2 ns to 4 s
TimeOut Trigger (Option)
Edge Type Rising, Falling, Rising/Falling
Timeout time 16 ns to 4 s
Duration Trigger (Option)
Pattern H, L, X
Trigger Condition >, <, <>
Duration Time 2 ns to 4 s
Setup/Hold Trigger
Edge Type Rising, Falling
Data Type H, L
Setup Time 2 ns to 1 s
Hold Time 2 ns to 1 s
RS232/UART Trigger
Polarity Normal, Invert
Trigger Condition Start, Error, Check Error, Data
Baud Rate 2400 bps, 4800 bps, 9600 bps, 19200 bps, 38400 bps, 57600
bps, 115200 bps, 230400 bps, 460800 bps, 921600 bps,
1Mbps, User
Data Bits 5 bit, 6 bit, 7 bit, 8 bit
I2C Trigger
Trigger Condition Start, Restart, Stop, Missing ACK, Address, Data, A&D
Address Bits 7 bit, 8 bit, 10 bit
Address Range 0 to 127, 0 to 255, 0 to 1023
