Rigol MSO2000A Series User Manual

Chapter 18 Specifications RIGOL
MSO2000A/DS2000A User’s Guide
18-7
Byte Length 1 to 5
SPI Trigger
Trigger Condition Timeout
Timeout Value 100 ns to 1 s
Data Bits 4 bit to 32 bit
Data Line Setting H, L, X
CAN Trigger (Option)
Signal Type Rx, Tx, CAN_H, CAN_L, Differential
Trigger Condition SOF, EOF, FrameType, FrameError
Signal Rate 10 kbps, 20 kbps, 33.3 kbps, 50 kbps, 62.5 kbps, 83.3 kbps,
100 kbps, 125 kbps, 250 kbps, 500 kbps, 800 kbps, 1 Mbps,
User
Sample Points 5% to 95%
Frame Type Data, Remote, Error, OverLoad
Error Type Bit Fill, AnswerError, CheckError, FormatError, RandomError
USB Trigger (Option)
Signal Speed Low Speed, Full Speed
Trigger condition SOP, EOP, RC, Suspend, Exit Suspend
