RIGOL Chapter 18 Specifications
MSO2000A/DS2000A User’s Guide
Measure
Cursor
Manual Mode
Voltage Deviation between Cursors (
V)
Time Deviation between Cursors (
T)
Reciprocal of
T (Hz) (1/
T)
Track Mode Voltage and Time Values of the Waveform
Point
Auto Mode Allow to display cursors during auto
measurement
Auto
Measurement
Analog channel:
Maximum, Minimum, Peak-Peak Value, Top Value, Bottom
Value, Amplitude, Average, Vrms-N, Vrms-1, Overshoot,
Pre-shoot, Area, Period Area, Period, Frequency, Rise Time,
Fall Time, Positive Pulse Width, Negative Pulse Width, Positive
Duty Cycle, Negative Duty Cycle, Delay A
ïƒ B , Delay
A
ïƒ B , Delay A ïƒ B , Delay A ïƒ B , Phase A ïƒ B ,
Phase A
ïƒ B , Phase A ïƒ B , Phase A ïƒ B
Digital channel:
Frequency, Period, Positive Pulse Width, Negative Pulse Width,
Positive Duty Cycle, Negative Duty Cycle, Delay A
ïƒ B ,
Delay A
ïƒ B , Delay A ïƒ B , Delay A ïƒ B , Phase
A
ïƒ B , Phase A ïƒ B , Phase A ïƒ B , Phase A ïƒ B
Number of
Measurements
Display 5 measurements at the same time.
Measurement
Range
Screen or cursor
Measurement
Statistic
Current Value, Average, Max, Min, Standard Deviation,
Number of Measurements
Frequency
Counter
Hardware 6 bits frequency counter
(channels are selectable)
