Chapter 18 Specifications RIGOL
MSO2000A/DS2000A User’s Guide
18-9
Math Operation
Waveform
Operation
A+B, A-B, A×B, A÷B, FFT, Digital Filter, Editable Advanced
Operation, Logic Operation
FFT Window
Function
Rectangle, Hanning, Blackman, Hamming
FFT Display Split, Full Screen
FFT Vertical Scale Vrms, dB
Logic Operation AND, OR, NOT, XOR
Math Function Intg, Diff, Log, Exp, Sqrt, Sine, Cosine, Tangent
Number of Buses
for Decoding
2
Decoding Type Parallel (standard), RS232/UART (option), I2C (option), SPI
(option), CAN (option)
Display
Screen Type 8.0 inches (203 mm) TFT LCD display
Display
Resolution
800 Horizontal ×RGB×480 Vertical Pixel
Display Color 160,000 Color (TFT)
Persistence Time Min, 50ms, 100ms, 200ms, 500ms, 1 s, 2 s, 5 s, 10 s, 20 s,
Infinite
Display Type Dots, Vectors
Real-time Clock Time and Date (user adjustable)
