Rigol MSO2000A Series User Manual

RIGOL Chapter 18 Specifications
MSO2000A/DS2000A User’s Guide
18-10
Signal Source (MSO2000A-S/DS2000A-S)
Channels 2
Sample Rate 200 MSa/s
Vertical
Resolution
14 bits
Max. Frequency 25 MHz
Standard
Waveform
Sine, Square, Pulse, Ramp, Noise, DC
Built-in
Waveform
Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, Lorentz,
Haversine
Sine Frequency
Range
100 mHz to 25 MHz
Flatness ±0.5 dB (relative to 1 kHz)
Harmonic
Distortion
-40 dBc
Stray
(Non-harmonic)
-40 dBc
Total Harmonic
Distortion
1%
S/N Ratio 40 dB
Square/Pulse Frequency
Range
Square: 100 mHz to 15 MHz
Pulse: 100 mHz to 1 MHz
Rise/Fall Time <15 ns
Overshoot <5%
Duty Cycle Square: 50%
Pulse: 10% to 90% (user adjustable)
Duty Cycle
Resolution
1% or 10 ns (the larger of the two)
Min. Pulse
Width
20ns
Pulse Width
Resolution
10 ns or 5 bits (the larger of the two)
Jitter 500 ps
Ramp Frequency
Range
100 mHz to 100 kHz
Linearity 1%
