RIGOL Chapter 5 To Trigger the Oscilloscope
5-34 MSO5000-E User Guide
Parity:
Used to verify whether data are properly transmitted. Press More → Parity, then
rotate the multifunction knob to select the desired parity. Then press down the
knob to select it. You can also press Parity continuously or enable the touch screen
to select the parity. The available parity include "None", "Odd", and "Even".
Polarity
Press More → Polarity, then select the polarity of data transmission. It can be set
to "Pos" or "Neg" .
Baud Rate:
Press More → Baud Rate, then select the baud rate of data transmission (i.g.
specifies a clock frequency). Three setting methods are available for baud rate:
âš« Press Baud Rate, then set the user-defined baud rate with the displayed
numeric keypad.
âš« Press Baud Rate, then select the preset baud rate from the available options.
The available baud rates include 50 bps, 75 bps, 110 bps, 134 bps, 150 bps, 300
bps, and etc.
âš« Press Baud Rate, then rotate the multifunction knob to adjust the baud
rate at a small step.
Trigger Mode:
In the trigger control area (Trigger) on the front panel, press Mode to quickly switch
the current trigger mode. For details, refer to descriptions in "Trigger Mode".
Trigger Parameter Setting:
Set the trigger parameter (noise rejection) under this trigger type. For details, refer
to descriptions in "Noise Rejection".
Trigger LEVEL/Threshold Level:
Rotate the Trigger LEVEL knob to adjust the trigger level/threshold level. Refer
to "Trigger LEVEL/Threshold Level". The current trigger level/threshold level
value is displayed at the upper-right corner of the screen.
