Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL
MSO5000-E User Guide 17-13
waveform.
⚫ Edit Points
Press Edit Points to enter the point editing menu. You can specify the voltage
value for each waveform point to define the waveforms.
➢ Current Point
Press PointX, then rotate the multifunction knob or use the pop-up
numeric keypad to select the points to be edited. The available range is
from 1 to the number of initial points.
➢ Voltage
Press Voltage, then rotate the multifunction knob or use the pop-up
numeric keypad to set the voltage value of the current point. Its available
range is from -2.5 V to +2.5 V.
➢ Insert
Press Insert to insert a new editable point between the current editing
point and the next editing point. The number of initial points adds 1
automatically. You can press Insert continuously to increase the editable
points gradually.
➢ Delete
Press Delete to delete the current point from the waveform, and connect
the remaining points with the current interpolation method.
➢ Zoom
Press Zoom continuously to enable or disable the zoom function of
horizontal timebase.
➢ Apply
Press Apply to apply the current settings for the currently edited arbitrary
waveforms and output the edited waveforms.
⚫ Save the arbitrary waveform
Press Save to enter the file saving interface. Please refer to descriptions in
"Store and Load" to save the currently edited waveform file to the internal or
external memory in "*.arb" format (you can overwrite the original file or save
the currently edited waveform again).
Modulation
The built-in Function/Arbitrary Waveform Generator of MSO5000-E series
oscilloscope supports amplitude modulation (AM), frequency modulation (FM), and
frequency-shift keying modulation (FSK). A modulated waveform consists of a carrier
waveform and a modulating waveform. The carrier waveform is the waveform output
from the Function/Arbitrary Waveform Generator, and the modulating signal can be
the built-in sine, square, triangle waveform, or noise signal.
Press Settings → Type, and rotate the multifunction knob to select
