Chapter 6 Operations and Measurements RIGOL
MSO5000-E User Guide 6-43
source channels are None, CH1-CH2, LA, and Math1-Math4.
Note:
⚫ Only channels currently enabled can be selected.
⚫ When "LA" is selected under Source, Select is grayed out and disabled. By
default, "X" is selected under Select.
3. Adjust Cursor Position
1) When "X" is selected under Select, you can adjust the position of X cursor.
⚫ Press AX, then rotate the multifunction knob to adjust the
horizontal position of Cursor A (X cursor). Its adjustable range is
limited within the screen.
⚫ Press BX, then rotate the multifunction knob to adjust the
horizontal position of Cursor B (X cursor). Its adjustable range is
limited within the screen.
⚫ Press AX BX, then rotate the multifunction knob to adjust the
horizontal position of Cursor A and Cursor B (X cursors) simultaneously.
Its adjustable range is limited within the screen. The horizontal spacing
between Cursor A and Cursor B (X cursors) remains unchanged.
2) When "Y" is selected under Select, you can adjust the position of Y cursor.
⚫ Press AY, then rotate the multifunction knob to adjust the vertical
position of Cursor A (Y cursor).
⚫ Press BY, then rotate the multifunction knob to adjust the vertical
position of Cursor B (Y cursor).
⚫ Press AY BY, then rotate the multifunction knob to adjust the
vertical position of Cursor A and Cursor B (Y cursors) simultaneously.
The vertical spacing between Cursor A and Cursor B (Y cursors)
remains unchanged.
Note: If one of the three items (AX, BX, and AX BX) or one of the three items
(AY, BY, and AY BY) is selected, you can press down the multifunction knob
continuously to switch among the three items.
4. Select Screen Region
⚫ When the delayed sweep function is disabled, press More, and "Main" is
automatically selected under Region and cannot be modified.
⚫ When the delayed sweep function is enabled, the screen is divided into two
regions: main timebase and zoomed timebase. Press Region continuously
to select "Main" or "Zoom".
➢ When "Main" is selected, the cursor is displayed in the main timebase
region, and you can measure the parameters in the main timebase
region.
➢ When "Zoom" is selected, the cursor is displayed in the zoomed
timebase region, and you can measure the parameters in the zoomed
timebase region.
