Rigol MSO5000-E Series User Manual

Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL
MSO5000-E User Guide 17-11
select "Offset" or "Low Level". You can also press Offset or Low Level
continuously to select it. Also, you can enable the touch screen to select it.
Rotate the multifunction knob or use the pop-up numeric keypad to set the
offset or low level value of the current signal.
⚫ Set the initial number of points
The initial number of points indicates the number of editable points. By default,
the number of editable points of arbitrary waveforms created can be preset to 2.
Point 1 is fixed at 0 s and Point 2 is fixed at the middle of the period. Press Init
Points, then rotate the multifunction knob or use the pop-up numeric
keypad to set the number of editable points for the arbitrary waveform. The
maximum number of editable points supported by the system is 16,384 (16
kpts).
⚫ Linear interpolation
Press Linear Interp to enable or disable the linear interpolation between the
defined points of the waveform.
➢ ON: the waveform editor connects two points using a straight line.
➢ OFF: the waveform editor will keep a constant voltage level between two
points and create a ladder-like waveform.
⚫ Edit points
Press Edit Points to enter the point editing menu. You can specify the voltage
value for each waveform point to define the waveforms.
➢ Current Point
Press PointX, then rotate the multifunction knob or use the pop-up
numeric keypad to select the points to be edited. The available range is
from 1 to the number of initial points.
➢ Voltage
Press Voltage, then rotate the multifunction knob or use the pop-up
numeric keypad to set the voltage value of the current point. Its available
range is from -2.5 V to +2.5 V.
➢ Insert
Press Insert to insert a new editable point between the current editing
point and the next editing point. The number of initial points adds 1
automatically. You can press Insert continuously to increase the editable
points gradually.
➢ Delete
Press Delete to delete the current point from the waveform, and connect
the remaining points with the current interpolation method.
➢ Zoom
Press Zoom continuously to enable or disable the zoom function of
horizontal timebase.
➢ Apply
Press Apply to apply the current settings for the currently edited arbitrary
