RIGOL Chapter 17 Function/Arbitrary Waveform Generator (Option)
17-20 MSO5000-E User Guide
➢ Manual: when you press Manual Trig for one time, one burst output is
immediately launched for the corresponding channel. For the Infinite
burst type, the Cycles menu is disabled and grayed out.
âš« Set the burst period
It is defined as the time from the beginning of one burst to that of another
burst.
Press Burst Period, then rotate the multifunction knob or use the
pop-up numeric keypad to set the desired burst period. Its available range
is from 1 us to 500 s. By default, it is 10 ms.
