RIGOL Chapter 20 System Utility Function Setting
20-16 MSO5000-E User Guide
When the Quick shortcut key is set to "Save Group", set the Group parameter.
Press Quick on the front panel to save the group.
âš« Operation Type
Press Operation and then rotate the multifunction knob to select "Save
Group". Press down the knob to select it. You can also press Operation
continuously to select among the options, or enable the touch screen to tap
the desired operation type.
âš« Group
Set the Group parameter: press Group and then rotate the multifunction
knob to select "Save Image", "Save Wave", or "Save Setup". Press down
the knob to select the desired one. You can also press Group continuously
or enable the touch screen to select it. You can select any or all of the three
items. The sign indicates that the item has been selected, and
indicates that the item has not been selected.
Screen Saver
When the oscilloscope enters the idle state and holds for a certain period of time, the
screen saver program will be enabled.
Press Utility → More → Screen Saver to enter the screen saver setting menu.
Press Screen Saver, then rotate the multifunction knob to select the screen
saver type, and then press down the knob to select the type. You can also press
Screen Saver continuously or enable the touch screen to select the desired type.
The available screen saver types include "Off", "Picture", and "Text". The screen
saver program is disabled by default.
1. Select the Screen Saver
âš« If you select "Off" under Screen Saver, it indicates that the screen saver is
disabled.
âš« If you select "Picture" under Screen Saver, press Select Picture to select
the file. The file types include "*.png", "*.bmp", "*.jpg", and "*.tif".
âš« If you select "Text" under Screen Saver, press Text, and then the
filename input interface is displayed, e.g. inputting "RIGOL Scope". For
details, refer to descriptions in "To Create a Folder".
2. Set the Wait Time
Press Time to Start, rotate the multifunction knob or use the pop-up
numeric keypad to input the screen saver time. The available range is from 1
min to 999 min.
