RIGOL Chapter 21 Remote Control
21-8 MSO5000-E User Guide
If the resource cannot be searched automatically:
âš« Select the GPIB card address of the PC from the drop-down box of
"GPIB0::" and select the GPIB address set in the oscilloscope from the
drop-down box of "0::INSTR".
âš« Click to check whether the GPIB communication works
normally; if not, please follow the corresponding prompt messages to
handle it.
5. View the device resource
The searched instrument resource will be under the directory of "RIGOL Online
Resource".
6. Control the instrument remotely
Right-click the resource name "MSO5152-E (GPIB0::18::INSTR)", and select
"SCPI Panel Control" to open the remote command control panel. Then you can
send commands and read data through the panel.
