ProSYS Quick Programming Setup 27
Fuses:
F1: Battery power 3.0 A
F2: Auxiliary power 2.0 A
F3: Bell/loudspeaker power 1.0 A
3A Power Supply Expansion Module
Input Power:
16.5VAC @ 50VA (via 230VAC / 16.5VAC/50Hz transformer)
Rechargeable Standby
Battery:
12V Up To 21 Amp-Hours (AH)
Power Outputs:
Auxiliary Power: 3A @13VDC
Bell/LS (External) Sounder Output: 1.7A @13VDC
Overload Protection:
Automatic Electronic Protection
On board Utility Outputs:
2 relays, 12VDC @ 3A max Dry Contact Relays
Event Log Expansion Module
Current Consumption:
13.8VDC +/-10%; 30 mA, maximum
Printer Module (Not UL Listed)
Current Consumption:
13.8VDC +/-10%; 10 mA, maximum
X-10 Transmitter Module (Not UL Listed)
Current Consumption:
13.8VDC +/-10%; 30 mA maximum
Access Control Module (Not UL Listed)
Current Consumption:
13.8VDC +/-10%; 100 mA maximum
Input power:
13.8V DC + 10%
Readers Consumption:
5V / 150 mA maximum
Relay:
24V DC / 1 A maximum
Proximity Key Reader (Not UL Listed)
Current Consumption:
13.8VDC +/-10%; 70 mA, typical / 180 mA maximum
Advance Digital Voice Module
Current Consumption:
13.8VDC +/-10%; 38 mA typical / 70 mA maximum
Voice Message Unit
Input Power:
8V DC to 14V DC
Current Consumption:
9 mA (standby) /
60 mA (active speaking - normal volume) /
130 mA (active speaking - full volume)
GSM/GPRS Communication Module
Input Power:
13.8VDC ±10%
Battery: Lead Acid (rechargeable), 12VDC/1.2Ah
Current Consumption:
During Communication - 300mA, During Standby - 70mA
Advanced Communication Module (ACM)
Current Consumption:
9-16 VDC +/-10%; 300mA@13VDC
Fast PSTN Modem 2400 BPS (Not UL Listed)
Current Consumption:
100 mA maximum
CE Declaration of Conformity
Hereby, RISCO Group declares that this control panel (ProSYS 128, ProSYS 40, ProSYS 16), with
wired accessories (including cables) and wireless accessories, is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
For the CE Declaration of Conformity please refer to our website: www.riscogroup.com.
Compliance Statement
Hereby, RISCO Group declares that the ProSYS series of control panels and accessories are suitable
for use in systems designed to comply with PD6662:2004 Security Grade 3, Environmental Class II.
(Security Grade 2 when using Wireless accessories).
The ProSYS series of control panels and accessories comply with the relevant parts of the EN50131
series of standards.
The ProSYS series of control panels and accessories comply with DD243:2004.
