ProSYS Quick Programming Setup 17
Programming: Dialer (For PSTN Dialing)
The bold sub headings below are ‘Main Menu’ headings.
The
key is pressed to move into the various sub menus.
To return to the ‘Main Menu’ headings at any time, press
repeatedly.
DIALER - Link-Up (MS Telephone numbers and Communication format)
QUICK KEYS = [5][1]
1. Using the / keys, select [LINK-UP] and press .
2. Using the
/ keys, select [MS LINK-UP] and press .
3. Using the
/ keys, select [MS 1 LINK-UP] and press .
4. Using the
/ keys, select [PSTN/VOICE] and press .
Note:
It is the assumption that a regular phone line is used for communication to MS.
5. Using the numeric keys, enter the Primary MS phone number and press .
6. Using the
/ keys, select [MS 2 LINK-UP] and press .
7. Using the
/ keys, select [PSTN/VOICE] and press .
Note:
It is the assumption that a regular phone line is used for communication to MS.
8. Using the numeric keys, enter the Secondary MS phone number and press .
DIALER - Accounts (Site Code/ID)
QUICK KEYS = [5][2]
1. Using the / keys, select [ACCOUNTS] and press .
2. Using the
/ keys, select the relevant Partition and press .
3. Using the
/ keys, select [FOR ACR 1] and press .
4. Using the numeric keys, enter the Site Code/ID for Partition 1 / MS 1 and press
.
5. Using the
button, select ‘Y’ or ‘N’ to apply the Site Code/ID to all partitions and
press
.
Note:
If each partition requires a different Site Code/ID, repeat step 3 - 5 selecting the relevant partition
DIALER - Communication Format (Transmission protocol to MS)
QUICK KEYS = [5][3]
1. Using the / keys, select [COMM FORMAT] and press .
2. Using the
/ keys, select [FOR MS 1] and press .
3. Using the numeric keys, enter the transmission format code and press
.
Note:
0420 for Contact/Point ID – 0700 for SIA
4. Using the / keys, select [FOR MS 2] and press .
5. Using the numeric keys, enter the transmission format code and press
.
Note:
0420 for Contact/Point ID – 0700 for SIA
