Riva 90 ARGO - Page 168

6 - WATER SYSTEMS 162
Black water system diagram - Lower deck
To upper deck
To lower deck
Centralized overboard
Watertight bulkhead p.
Pump out flange
Ball valve
Check valve
Manifold
Overboard
Multi-purpose unit:
Bilge pump
Grey water pump
Black water pump
Siphon break
Fan coil unit
Odor removing filter
Three-way valve
Tee
Y
Grey water pumping unit
Condensation pumping unit
Odor removing siphon
Black water treatment system
Dosing unit
Feeding pump
Air compressor
Sludge tank
Compressed air tank
LOWER DECK
