7 - ELECTRIC SYSTEM185
7.2 ELECTRICAL PANELS
Main electrical panel:
The electrical system is controlled from the control panel located in the sys-
tem room.
To simplify the descriptions of the electrical panel, the following main sec-
tions have been identied:
A. 230V AC 50Hz Section
B. 24V DC Section
CAUTION
Before removing the front panel for maintenance, stop the power genera-
tors, disconnect the shore sockets and the inverter.
NOTE
For a detailed description refer to the electric installation manual.
A
B
