7 - ELECTRIC SYSTEM 196
Main deck electrical panel:
To the right of the ladder leading to the pilothouse, there is an electrical pan-
el equipped with various magneto-thermal switches to protect the various
uses in the galley and on the main deck.
To make the description of the electrical panel more understandable, the
following main sections have been identied:
A. 230V AC 50Hz Section
B. 24V DC Section
CAUTION
Before removing the front panel for maintenance, stop the power genera-
tors, disconnect the shore sockets and the inverter.
NOTE
For a detailed description refer to the electric installation manual.
