11 - AUXILIARY EQUIPMENT ON BOARD323
11.7 GARAGE HATCH AND LINEAR LIFT
GARAGE HATCH
At the stern of the yacht is the garage, capable of accommodating inside a
tender and a jet ski.
The garage is accessible through the opening of an electro-hydraulic door.
The operating controls for the system are located on the access ladder to
the aft cockpit, port side.
The garage hatch is moved together with the aft platform thanks to an elec-
tro-hydraulic control unit (24V) located on the port side in the engine room.
1. Garage light button
2. Garage opening button
3. Garage lock button
4. Electro-hydraulic power pack
DANGER
The garage hatch must always be closed during navigation, making sure
that the locking devices are in place.
DANGER
Never navigate with the garage hatch incorrectly and completely closed.
This prohibition also applies to low speed manoeuvres with thrusters.
21
3
4
