Main Display
The main display shows the current preset or song name as well as status of the PBC’s loops, switches, buffers and
outputs.
1. Audio Loop Indicators – indicates which of the 10 audio loops are currently active
2. Function Switch Indicators – indicates which of the four function switches are currently active
3. Buffer Indicators – indicates which of the three internal audio buffers are currently active
4. Output Indicators – indicates which of the two audio outputs are active
1 2 3 4 5 6 7 8 9 0
1 2 3 4 A B1 2 3
001
Preset 001
1
2
3
4
1
