Unit assembly
26 © robatherm
Connection of AHUs with roof rack frame
The roof rack frame is used to install two AHUs on top of each other. The sections are only connected
to each other at the final installation site.
WARNING
Danger to life due to suspended loads and falling objects
Risk of death due to failure of transport lugs or transport loops.
• Transport and unload sections only with suitable and approved lifting
equipment (ropes, chains, lifting straps, turnbuckles) in accordance with BGV
D6.
• Attach sections only to transport lugs or transport loops.
• Lifting equipment must be approved for the weight of the section.
• For transport lugs, the inclination angle between the lifting equipment must be
between 45° and 55°.
• For transport loops, the maximum permissible oblique pull is 10°.
• Observe reduction of load-carrying capacity by spreading the lifting equipment
according to the lifting equipment table.
• Observe safety regulations of the conveying vehicles and means of transport.
• Do not stand under suspended loads.
