3. Pallet loading/unloading ramps:
one ramp (3) is supplied as a standard and can be placed in 5 positions (every 45°).
It is possible to purchase a second and a third optional ramp or a 270° ramp (3A) (3 pieces) which covers all
the positions.
4. Lifting frame:
Structure which allows lifting the machine from the ground when the floor must be washed or for loading with
electric hand pallet trucks.
- Underground installation template:
profiled structure for base underground installation.
- Rotary table (ø1800):
it is used to wrap pallets with a size greater than the standard one.
- Brake shaft for mesh (only for “FRD” spool carriages):
it is used to obtain a correct tensioning of the mesh.
- Slide shaft (2400 - 2800 - 3100 mm):
it is used to wrap pallets which are higher than the standard ones.
