Robopac Masterplat PLUS TP3 FRD User Manual

ENG
TECHNICAL INFORMATION
48
3.9.3. MACHINE TECHNICAL FEATURES
Description
Unit of
measurement
Value
Supply voltage
V
220-240 1Ph
220-240 3Ph
380-415 3Ph+N
120 1Ph
Power supply frequency
Hz
50/60
Installed power
kW
1.5 (Masterplat PLUS FRD)
1.9 (Masterplat PLUS PGS)
Table rotation speed
C = 1650
rpm
5 - 12
C = 1800
5 - 11
Carriage upstroke / downstroke speed
m/min.
1.4 - 4
Maximum capacity
kg
1500
Overall weight
kg
525 (Masterplat PLUS TP3
FRD)
550 (Masterplat PLUS TP3
PGS)
Ambient operating temperature.
°C
0÷40
Ambient operating temperature (FREEZER model)
°C
-30 ÷ +40
(1)
(1)
On request, also the “INOX” model can operate at this temperature.
3.9.4. PRESSER TECHNICAL FEATURES
Description
Value
Working pressure
6 (±1) bar (0.6±0.1 MPa)
Pneumatic cylinder with rod
H = 2200/2400
2800/3100
Air consumption 11 NI/min.
