TECHNICAL INFORMATION
40
3.7.3. "MASTERPLAT PLUS PGS USA" MACHINE AND PALLET DIMENSIONS
Description
Masterplat PLUS PGS
Standard
Optional
Optional
Optional
Shaft height
2200
2400
2800
-
A
H
2865
3065
3465
-
B
2560
2760
3160
-
H1
2200
2400
2800
-
M
77.5
77.5
77.5
-
Load overall
dimensions
 1650
-
-
-
C
1650
-
-
-
D
2760.5
-
-
-
E
1745
-
-
-
F
G
N
L
1000
-
-
-
W
1200
-
-
-
Weight (kg)
2000
-
-
-
3.7.4. MACHINE TECHNICAL FEATURES
Description
Unit of
measurement
Value
Supply voltage
V
220-240 1Ph
220-240 3Ph
380-415 3Ph+N
120 1Ph (for USA)
Power supply frequency
Hz
50/60
60 (for USA)
Installed power
kW
1.5 (Masterplat PLUS
FRD)
1.9 (Masterplat PLUS
PGS)
Table rotation speed
C = 1650
rpm
5 - 12
C = 1800
5 - 11
Carriage upstroke / downstroke speed
m/min.
1.4 - 4
Maximum capacity
kg
2000
Overall weight
kg
395÷455
Ambient operating temperature.
°C
0÷40
Ambient operating temperature (FREEZER model)
°C
-30 ÷ +40
(1)
(1)
On request, also the “INOX” model can operate at this temperature.
3.7.5. PRESSER TECHNICAL FEATURES
Description
Value
Working pressure
6 (±1) bar (0.6±0.1 MPa)
Pneumatic cylinder with rod
H = 2200/2400
2800/3100
Air consumption 11 NI/min.
