Robotiq Hand-E C10 Gripper Instruction Manual
INFO
The activation will allow the gripper to adjust to any fingers/fingertips. No matter what is the size and/or
shape of the fingers/fingertips, 0 will always be fully opened and 255 fully closed, with a quasi-linear
relationship between the two values.

4.3.5. Register: SPEED
Address: Byte 4
Bits 7 6 5 4 3 2 1 0
Symbol rSP
This register is used to set the gripper closing or opening speed in real time, however, setting a speed will not initiate a motion.
l
0x00 - Minimum speed
l
0xFF - Maximum speed
4.3.6. Register: FORCE
Address: Byte 5
Bits 7 6 5 4 3 2 1 0
Symbol rFR
The force setting defines the final gripping force for the gripper. The force will fix the maximum current sent to the motor . If the
current limit is exceeded, the fingers stop and trigger an object detection notification. Please refer to the Picking Features section
for details on force control.
l
0x00 - Minimum force
l
0xFF - Maximum force

INFO
Register bytes 6 to 15 are reserved and should be set to 0.

4.4. Robot Input Registers andStatus
4.4.1. Register: GRIPPERSTATUS
Address: Byte 0
Bits 7 6 5 4 3 2 1 0
Symbols gOBJ gSTA gGTO Reserved gACT
46
