Moving Mouth
Function
- The moving mouth is a feature where the mouth moves as the operator speaks
through the robot. The amount of the movement is affected by the level of volume of the
voice. This level is affected by the Receiver volume level and the position of the headset
microphone to the operator's mouth. The sensitivity is set based on a typical voice
volume and the headset microphone being about 1 inch from the operator’s mouth.
Adjustment-
The adjustment is preset at the factory and should not need any adjustment. If an
adjustment is necessary, see the Main Circuit Board diagram in the Appendix for the
location of it. It is labeled Moving Mouth sensitivity. When this pot is adjusted clockwise
this makes the mouth more sensitive to your voice and turning it counter-clockwise
makes it less sensitive.
Location of the Adjustment
Main Electronics Box in Vehicle.
