57
Main Electronics Box
Fuse Block
See Fuse Block Detail
Diagram for
Fuse size and circuit
Main Circuit
Board
Active Fil
ter
MP3 Player Option or Tape Player
RC Receiver
On/Off Switch
Battery Connection
