Robotronics Vehicle Robot - Vehicle Top 1 Underside View

62
Vehicle Top 1 – Underside View
Right Eyelid Servo
37 Pin Connector
Servo Arm
Servo Arm
Eye Servo Board
(Opto-shift board)
Right Body Latch
Left Body Latch
Rear Body Latches
Eyelid Rod
Eyelid Rod
Left Eyelid Servo
Eyes L/R Servo
Eye Plate
Top Style 1 Robots: Freddie, Buster, Andy, Barney, Toby
Servo Arm Set Screw
(M2.5 x .45 x 8mm Phillips Pan
Head Machine Screw)
