Robotronics Vehicle Robot - Robot Frame Top View 1

55
Robot Frame - Top View 1
Fan
On/Off Switch
Battery strap
Road Rage
Audio Amp
MP3 Player
RC Receive
r
RC Receiver
Antenna
Serial No./Model No.
Sticker
151 Voice Transmitter
37 Pin Connection
Wire to upper robot
connects here.
V
oice Modifie
r
Battery Connector
Voice Receiver
Raise Antennas
Headlight/Body Light
Connection and Fuse
Audio Amp
Master Volume
S
p
eaker Wire
S
p
eaker Wire
