6 SENTINEL MESSAGES
6.1 Prealarm messages
Visualized
message
Meaning
T1>Tlim Suction temperature higher than the prealarm value
T2>Tlim Discharge temperature higher than the prealarm value
T3>Tlim Drive side oil temperature higher than the prealarm value
T4>Tlim Gear side oil temperature higher than the prealarm value
T5>Tlim Enclosure temperature higher than prealarm value
P1<Plim Suction pressure lower than the prealarm value
P2>Plim Discharge pressure higher than the prealarm value
n<nlim Blower speed lower than the prealarm value
6.2 Alarm / Blower stop messages
Visualized
message
Meaning
T1>Tmax Suction temperature higher than the alarm value
T2>Tmax Discharge temperature higher than the alarm value
T3>Tmax Drive side oil temperature higher than the alarm value
T4>Tmax Gear side oil temperature higher than the alarm value
T5>Tmax Enclosure temperature higher than alarm value
P1<Pmax Suction pressure lower than the alarm value
P2>Pmax Discharge pressure higher than the alarm value
n<nmin Blower speed lower than the alarm value
n>nmax Blower speed higher than the alarm value (Frequency converter supply)
<-> The blower rotates in wrong direction
NO OIL Oil level lower than the minimum one allowed
