ButterCup Installation - Damper Shaft
Install the lower ButterCup housing bumper into the lower ButterCup Install the lower ButterCup housing bumper into the lower ButterCup
housing, wide side down, in alignment with the bolt.housing, wide side down, in alignment with the bolt.
Apply Threadlocker Loctite 242 (blue), or equivalent, to three full outer Apply Threadlocker Loctite 242 (blue), or equivalent, to three full outer
threads on the lower ButterCup housing. threads on the lower ButterCup housing.
Position the upper ButterCup housing and bumper above the vise Position the upper ButterCup housing and bumper above the vise
blocks. blocks.
Install the lower ButterCup housing/bumper assembly onto the Install the lower ButterCup housing/bumper assembly onto the
ButterCup shaft end plate; insert the bolt through the end plate bolt ButterCup shaft end plate; insert the bolt through the end plate bolt
hole.hole.
Slide lower cup to the upper bumper end plate, and position the Slide lower cup to the upper bumper end plate, and position the
alignment bolt through the hole on the end plate. alignment bolt through the hole on the end plate.
Thread the upper ButterCup housing onto the lower ButterCup housing Thread the upper ButterCup housing onto the lower ButterCup housing
finger tight.finger tight.
5
6
Theadlocker Loctite 242 - Blue
