Control Module Installation
Tighten each set screw evenly finger tight to center the Control Module Tighten each set screw evenly finger tight to center the Control Module
position on the top cap.position on the top cap.
Tighten each set screw to the specified torque.Tighten each set screw to the specified torque.
NOTICE
To avoid permanent damage to the compression damper top cap, do
not over tighten the set screws.
Remove the battery block from the Control Module.Remove the battery block from the Control Module.
Install the battery onto the Control Module.Install the battery onto the Control Module.
Control Module and Damper Homing:Control Module and Damper Homing: When the battery is installed, When the battery is installed,
the Control Module motor will activate and automatically reset and the Control Module motor will activate and automatically reset and
adjust the compression damper to the full open position. If the Control adjust the compression damper to the full open position. If the Control
Module is properly installed, the action should operate smoothly and Module is properly installed, the action should operate smoothly and
quickly. quickly.
If a clicking noise, or repeating motor actions are heard and felt, If a clicking noise, or repeating motor actions are heard and felt,
the Control Module is installed incorrectly. The output driver and the Control Module is installed incorrectly. The output driver and
compression damper keys may not be aligned correctly. compression damper keys may not be aligned correctly.
Adjust Alignment:Adjust Alignment:
1. Remove the battery.1. Remove the battery.
2. Partially and evenly loosen each set screw. Do not remove the set 2. Partially and evenly loosen each set screw. Do not remove the set
screws or the Control Module. screws or the Control Module.
3. Reinstall the battery.3. Reinstall the battery.
4. The Control Module and damper adjuster keys should self align and 4. The Control Module and damper adjuster keys should self align and
reset the damper compression position. reset the damper compression position.
5. Tighten each set screw to the specified torque.5. Tighten each set screw to the specified torque.
If alignment adjustment was unsuccessful, remove the Control Module, If alignment adjustment was unsuccessful, remove the Control Module,
align the output driver and compression keys, and reinstall the Control align the output driver and compression keys, and reinstall the Control
Module onto the compression damper top cap. Repeat Control Module Module onto the compression damper top cap. Repeat Control Module
Installation steps 1 - 5.Installation steps 1 - 5.
4
2 mm 2 mm
2 mm 0.25 - 0.5 N•m (2.2 - 4.3 in-lb) 2 mm 0.25 - 0.5 N•m (2.2 - 4.3 in-lb)
5
