22 Publication IASIMP-QS003B-EN-P - October 2009
Chapter 1 Prepare the CompactLogix Hardware
Follow These Steps
Complete the appropriate steps to assemble your 1768-L43/L45 CompactLogix hardware.
page 25
Assemble the 1768
CompactLogix
System
Make EtherNet/IP
Network
Connection
Wire the
1768-PA3 Power
Supply
page 28
page 32
page 24
Mount and Wire
the Line Interface
Module
Make DeviceNet
Network
Connections
page 29
1768
CompactLogix
System
Line Interface
Module
Ethernet
Switch
DeviceNet Network
Through-the-door
Disconnect for
LIM Module
