Rockwell Automation 1768-L45 User Manual

61Publication IASIMP-QS003B-EN-P - October 2009 61
Chapter 4
Prepare the PowerFlex 70 Drive
Introduction
In this chapter, you mount and wire power to a PowerFlex 70 drive. You also configure the
communication adapter and make network connections.
Before You Begin
• Assemble your CompactLogix hardware (Chapter 1).
• Determine which network adapter to use on the PowerFlex 70 drive:
– For an EtherNet/IP network (option 1), use the 20-COMM-E adapter.
– For a DeviceNet network (option 2), use the 20-COMM-D adapter.
What You Need
• PowerFlex 70 drive
• PowerFlex 70 communication adapter
– 20-COMM-E for an EtherNet/IP network (option 1)
– 20-COMM-D for a DeviceNet network (option 2)
• Standard CAT5 Ethernet cable for EtherNet/IP system (option 1)
