Rockwell Automation Publication 5094-UM001E-EN-P - April 2020 91
Configure the Standard Module Chapter 6
2. Select the module and click Create.
The New Module dialog box appears with a list of categories on the left
side. The number and type of categories varies by module type.
3. You can click OK to use the default configuration as shown or edit the
module configuration. The rest of this chapter describes how to edit
module configuration categories.
To add additional remote I/O modules with this method, complete one of
the following:
• If you cleared the Close on Create checkbox when you created the first I/O
module, repeat steps 2
…3.
• If you did not clear the Close on Create checkbox when you created the
first I/O module, repeat steps 1
…3.
