Kinetix 3 Drive Connector Data Chapter 3
Input Power Connector Pinout
Table 8 - Input Power (IPD) Connector
Shunt Resistor Connector Pinout
Table 9 - Shunt Resistor (BC) Connector
Motor Power Connector Pinout
Table 10 - Motor Power (MP) Connector
IPD Pin Description Signal
L1 Main AC power L1
L2 Main AC power L2
L3 Main AC power L3
L1C L1C - Control power L1C
L2C L2C - Control power L2C
DC DC bus negative (not supported) DC-
BC Pin Description Signal
B1 Shunt resistor +
DC bus positive (not supported)
B1
B2 Shunt resistor - B2
MP Pin Description Signal
UMotor power U U
VMotor power V V
WMotor power W W
