Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 117
Configure and Start the Kinetix 5500 Drive System Chapter 6
The axis (Axis_1 in this example) appears in the
Controller Organizer under Motion Groups>
Ungrouped Axes and is assigned as Axis 1.
6. Click Apply.
7. Click the Power tab.
You can configure an axis as Feedback Only. Refer to Configure Feedback Only
Axis Properties on page 124 for more information.
Single-phase operation is possible only when Module Properties>Power
tab>Bus Configuration is configured as Standalone.
The Logix Designer application enforces shared-bus configuration rules for
Kinetix 5500 drives, except for shared AC configurations.
