Chapter 6 Configure and Start the Kinetix 5500 Drive System
8. From the pull-down menus, choose the power options appropriate for your
actual hardware configuration.
9. Click OK.
10. Repeat step 1
through step 9 for each 2198-Hxxx-ERSx servo drive.
Attribute Menu Description
Voltage
• 400-480 VAC
• 200-240 VAC
AC input voltage class.
AC Input Phasing
• Three Phase
• Single Phase
Input power phasing. Kinetix 5500 drives with
single-phase operation is limited to 2198-H003-
ERSx, 2198-H008-ERSx, and 2198-H015-ERSx.
Bus Configuration
(1) (2)
(1) Refer to Chapter 3 for more information on single-axis and multi-axis configurations.
(2) Bus Configuration selection is not applicable to all EtherNet/IP drives.
Standalone
Applies to single-axis drives and drives with
Shared AC input configurations.
Shared AC/DC
Applies to converter drives with Shared AC/DC and
Shared AC/DC Hybrid input configurations.
Shared DC
Applies to inverter drives with Shared DC input
(common-bus) configurations.
Bus Sharing Group
(3) (2)
(3) For more information on bus sharing groups, refer to Understanding Bus Sharing Group Configuration on page 135.
Standalone Applies to standalone bus configurations.
• Group1
• Group2
• Group3…
Applies to any bus sharing configuration
(4)
.
(4) All drives physically connected to the same shared-bus connection system must be part of the same Bus Sharing Group in
the Logix Designer application.
Shunt Regulator Action
Disabled
Disables the internal shunt resistor and external
shunt option.
Shunt Regulator Enables the internal and external shunt options.
Shunt Regulator Resistor Type
Internal
Enables the internal shunt (external shunt option
is disabled).
External
Enables the external shunt (internal shunt option
is disabled).
External Shunt
(5)
(5) Refer to the Kinetix Servo Drives Specifications Technical Data, publication GMC-TD003, for more information on the
Bulletin 2097 external shunt resistors.
• None
• 2097-R6
• 2097-R7
Selects external shunt option. Only the shunt
model intended for the drive model is shown.
