Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 127
Configure and Start the Kinetix 5500 Drive System Chapter 6
Configure Induction Motor Axis Properties
The Kinetix 5500 servo drives support basic volts/hertz and sensorless vector
frequency control methods. For more information regarding frequency control
methods, refer to Induction Motor Control Methods
on page 223.
Follow these steps to configure induction motor axis properties.
1. In the Controller Organizer, right-click an axis and choose Properties.
2. Select the General category.
The General and Associated Module dialog box appears.
3. From the Axis Configuration pull-down menu, choose Frequency
Control.
4. From the Module pull-down menu, choose the drive to associate with your
Frequency Control axis.
The Module Type and Power Structure fields populate with the chosen
drive catalog number.
5. Click Apply.
6. Select the Motor category.
