Rockwell Automation Allen-Bradley Kinetix 5500 Series User Manual

Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 231
EC Certifications Appendix E
Document Control Number: IMC-0040-D-EN 2 / 3
Catalogue number Series
3
Description
Directive
4
EMC LVD MD
Bulletin 2198 Servo Drives
1
2198-H003-ERS
Kinetix 5500, Frame 1, 195-528Vrms, 0.6 kW, Inverter
1.0Amp, Safe Torque-Off
Yes Yes Yes
2198-H008-ERS
Kinetix 5500, Frame 1, 195-528Vrms, 1.6 kW, Inverter
2.5Amp, Safe Torque-Off
Yes Yes Yes
2198-H015-ERS
Kinetix 5500, Frame 2, 195-528Vrms, 3.2 kW, Inverter
5.0Amp, Safe Torque-Off
Yes Yes Yes
2198-H025-ERS
Kinetix 5500, Frame 2, 195-528Vrms, 5.2 kW, Inverter
8.0Amp, Safe Torque-Off
Yes Yes Yes
2198-H040-ERS
Kinetix 5500, Frame 2, 195-528Vrms, 8.4 kW, Inverter
13.0Amp, Safe Torque-Off
Yes Yes Yes
2198-H070-ERS
Kinetix 5500, Frame 3, 195-528Vrms, 14.9 kW, Inverter
23.0Amp, Safe Torque-Off
Yes Yes Yes
2198-H003-ERS2
Kinetix 5500, Frame 1, 195-528Vrms, 0.6 kW, Inverter
1.0Amp, Network Safe Torque-Off
Yes Yes Yes
2198-H008-ERS2
Kinetix 5500, Frame 1, 195-528Vrms, 1.6 kW, Inverter
2.5Amp, Network Safe Torque-Off
Yes Yes Yes
2198-H015-ERS2
Kinetix 5500, Frame 2, 195-528Vrms, 3.2 kW, Inverter
5.0Amp, Network Safe Torque-Off
Yes Yes Yes
2198-H025-ERS2
Kinetix 5500, Frame 2, 195-528Vrms, 5.2 kW, Inverter
8.0Amp, Network Safe Torque-Off
Yes Yes Yes
2198-H040-ERS2
Kinetix 5500, Frame 2, 195-528Vrms, 8.4 kW, Inverter
13.0Amp, Network Safe Torque-Off
Yes Yes Yes
2198-H070-ERS2
Kinetix 5500, Frame 3, 195-528Vrms, 14.9 kW, Inverter
23.0Amp, Network Safe Torque-Off
Yes Yes Yes
AC Line Filters
2198-DB08-F 460 Volt 7.5 Amp Three-Phase AC Line Filter Yes Yes N/R
2198-DB20-F 460 Volt 20 Amp Three-Phase AC Line Filter Yes Yes N/R
2198-DB42-F 460 Volt 42 Amp Three-Phase AC Line Filter Yes Yes N/R
Shunts
2097-R6 75 Ohm, 150W, External Shunt Resistor Yes Yes N/R
2097-R7 150 Ohm, 80 W, External Shunt Resistor Yes Yes N/R
Capacitor Module
2198-CAPMOD-1300 Kinetix5500 Capacitor Module Yes Yes N/R
1) Only the following motor and cable families are compatible with the Kinetix 5500 servo drives.
2) The following letters are used in the compatibility matrix to indicate model number description fields that do not
affect this DoC: x, y. These fields may be filled with any number(s) or letter(s).
3) If no series number is given, then all series are covered.
4) Legend as follows:
No = Product is not certified to this directive.
Yes = Product is certified to this directive.
N/R = this directive is not required for this product
