Appendix E EC Certifications
Document Control Number: IMC-0040-D-EN 3 / 3
Catalogue number Series
3
Description
Directive
4
EMC LVD MD
Motor Compatibility
1,2
VPL-Axxxxx-yyyyyy 230 Volt VP Low-inertia Servo Motor Yes Yes N/R
VPL-Bxxxxx-yyyyyy 460 Volt VP Low-inertia Servo Motor Yes Yes N/R
Cable Compatibility
1
2090-CSWM1DF-
YYAALL
Motor power/feedback cable for use with VP family
motors, YY = wire gauge, LL = length in meters
2090-CSBM1DF-
YYAALL
Motor power/feedback with brake cable for use with VP
family motors, YY = wire gauge, LL = length in meters
Connector Kits and Miscellaneous Accessories
2
2198-H040-x-x Input wiring connectors and DC bus T connector for
frame 1 and 2 servo drives
2198-H070-x-x Input wiring connectors and DC bus T connector for
frame 3 servo drive.
1585J-M8CBJM-x Shielded Ethernet cable N/R N/R N/R
1606-XLxxx 24V DC Power Supply N/R N/R N/R
2198-KITCON-DSL Replacement feedback connector kit for Kinetix 5500 N/R N/R N/R
2198-KITCON-IOSP Replacement I/O connector kit (spring clamp) for IOD
connector
2198-KITCON-IOSC Replacement I/O connector kit (screw terminal) for IOD
connector
2198-KITCON-PWR40 Replacement connector set, 40 Amp, for Kinetix 5500
Frame 1 & 2 drives
2198-KITCON-PWR70 Replacement connector set, 70 Amp, for Kinetix 5500
Frame 3 drives
N/R N/R N/R
1) Only the following motor and cable families are compatible with the Kinetix 5500 servo drives.
2) The following letters are used in the compatibility matrix to indicate model number description fields that do not
affect this DoC: x, y. These fields may be filled with any number(s) or letter(s).
3) If no series number is given, then all series are covered.
4) Legend as follows:
No = Product is not certified to this directive.
Yes = Product is certified to this directive.
N/R = this directive is not required for this product
