Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 33
Planning the Kinetix 5500 Drive System Installation Chapter 2
Shared AC Drive Systems
Table 10 - Fuse Selection (Bussmann part numbers)
Table 11 - Circuit Breaker Selection (Allen-Bradley catalog numbers)
Shared AC/DC and Hybrid Systems
Table 12 - Fuse Selection (Bussmann part numbers)
Table 13 - Circuit Breaker Selection (Allen-Bradley catalog numbers)
Kinetix 5500 Drive
Cat. No.
2 Axes 3 Axes 4 Axes 5 Axes
2198-H003-ERSx KTK-R-15
2198-H008-ERSx KTK-R-15
2198-H015-ERSx KTK-R-20 KTK-R-25 N/A
2198-H025-ERSx KTK-R-30 N/A
2198-H040-ERSx LPJ-35SP LPJ-45SP N/A
2198-H070-ERSx LPJ-60SP N/A
Kinetix 5500 Drive
Cat. No.
2 Axes
(1)
(1) UL has not approved circuit breakers for use as branch circuit protection for Kinetix 5500 drive systems.
3 Axes
(1)
4 Axes
(1)
5 Axes
(1)
2198-H003-ERSx
N/A
2198-H008-ERSx
2198-H015-ERSx 140U-D6D3-C15 140U-D6D3-C20 N/A
2198-H025-ERSx 140U-D6D3-C25 140U-D6D3-C30 N/A
2198-H040-ERSx N/A
2198-H070-ERSx N/A
Kinetix 5500 Drive
Cat. No.
2 Axes 3 Axes 4 Axes 5 Axes 6 Axes 7 Axes 8 Axes
2198-H003-ERSx KTK-R-10 KTK-R-15
2198-H008-ERSx KTK-R-15 KTK-R-20
2198-H015-ERSx KTK-R-20 N/A
2198-H025-ERSx KTK-R-30 N/A
2198-H040-ERSx KTK-R-30 LPJ-45SP LPJ-50SP N/A
2198-H070-ERSx LPJ-50SP N/A
Kinetix 5500 Drive
Cat. No.
2 Axes
(1)
3 Axes
(1)
4 Axes
(1)
5 Axes
(1)
6 Axes
(1)
7 Axes
(1)
8 Axes
(1)
2198-H003-ERSx N/A
2198-H008-ERSx N/A
2198-H015-ERSx 140U-D6D3-C15 140U-D6D3-C20 N/A
2198-H025-ERSx 140U-D6D3-C20 140U-D6D3-C30 N/A
2198-H040-ERSx 140U-D6D3-C30 N/A
2198-H070-ERSx N/A
(1) UL has not approved circuit breakers for use as branch circuit protection for Kinetix 5500 drive systems.
